AT4K – Mechanical Flange Alignment Tool Kit

The AT4K is a mechanical allignment tool kit used to align bolted flanges to aid the insertion or removal of the flange bolts.The kit contains an AT4 alignment tool and all items required to operate the tool safely, it is packaged in a robust carry case for easy transport and storage.

The AT4K can correct or prevent:

  • Linear Misalignment – when the axis of the flanges are not aligned.
  • Rotational Misalignment – when the axis of the flanges are aligned but the bolt holes are not aligned.

The AT4K produces a maximum alignment force of 40kN (8990 lbf) when the maximum torque of 68Nm (50lbf*ft) is applied with the Torque Wrench provided.
A powerful and portable tool, the AT4 weighs only 8Kg (17.6lbs) and is the correct tool for medium and small sized flange joints.

SKU: AT4K Category:

The AT4K is a mechanical flange alignment tool that is actuated by hand using a torque wrench included in the kit. It is used to apply an alignment force on the circumference of a flange whilst reacting against the bolt hole of the mating flange – this tool removes the requirement for rigging and anchor points used in traditional methods. The wing on the tool is mounted on roller bearings, this allows the tool to be used to prevent misalignment during flange spreading.

All RenQuip Alignment tools are designed to be used in conjunction with RenQuip Flange Spreading tools.

The Tool is lightweight and portable making it ideal for use in remote locations.

If more force is required multiple tools can be used.

All RenQuip tools are manufactured from the highest quality materials and 100% load tested resulting in highly durable, low maintenance products.

Maximum Alignment Force

40kN (8990 lbf)

Minimum Bolt Hole Diameter

22mm (0.87”)

Maximum Wing Reach

150mm (5.9”)

Maximum Drop Leg Reach

150mm (5.9”)

Tool Dimensions

100mm x 285mm x 380mm (3.9” x 11.2” x 15”)

Tool Weight

8Kg (17.6lbs)

Kit Weight

12Kg (26.5lbs)

Kit Dimensions

100mm x 285mm x 380mm (3.9” x 11.2” x 15”)

Kit Contents Image
1 x AT4 Tool
1 x Torque wrench
1 x Ratchet and Strap
1 x Instruction Manual
1 x Robust moulded carry case
