Case Study: AT4-1.8K

What was the requirement:
A customer required a flange alignment tool with a hook pin capable of fitting a flange fitted with M15 bolts, meaning the hook pin diameter needed to be 15mm.

What was the solution:
An AT4K Mechanical Flange Alignment Tool was modified by reducing its hook pin diameter down from 22mm to 15mm allowing it to fit the smaller diameter flange’s M15 bolt holes whole still producing a maximum reaction alignment force of 18kN when a torque of 30Nm (22ft.Lb) is applied to the tool.

Customer Feedback:
A space for feedback copy >>>>>>>>>>>>>>>>>>>
>>>>> >>>>>> >>>>> >>>>>>> >>>>> >>>> > > > >>>>>>>>

Discover more about the AT4-18K
